The 55-Series Fresh water Diaphragm pump is compact and designed for a wide range of applications and provides a high volume flow rate with reduced pump cycling. The pump is self-priming and can be run dry without harm and has an internal bypass feature which reduces pump cycling and features a built-in pressure switch, which automatically starts and stops the pump when the faucet is opened or closed.
51-Series Seaflo Pump | |
---|---|
SKU | SFDP1-040-013-060-51 |
Voltage | 12V |
Open Flow (LPM) | 15.1 |
Max Draw | 14A |
PSI/Bar | 60/4.2 |
Pump Specifications | |
---|---|
Type |
5 Chamber positive displacement diaphragm pump, self priming, capable of being run dry |
Control Type | Pressure switch |
Max Recommended Temperature | 60° C (140° F) |
Priming Capabilities | 1.8m suction lift |
Re-start Pressure |
Shut-on Pressure 20 : PSI Shut-off Pressure 60 : PSI |
Inlet/Outlet Ports | 1/2" (12,7mm) hose barb |
Weight | 2.8 kg |
Motor Specifications | |
---|---|
Leads | 14 AWG, 13" (33cm) long with 2-Pin connector/leads |
Duty Cycle | Continuous |
Max. Draw | 17 A |
Fuse Amps | 25.5 A |
