Veratron Viewline 52mm Transmission Oil Pressure 10Bar

Pressure

ViewLine 52 mm Pressure Gauges are equipped with a red warning LED as a standard. The warning point depends on the chosen pressure sensor with warning contact or can be controlled by installing a make-point switch. Anti-fog plastic double lens, maximum precision and stylish design with choice of nine various bezels. The 0-5 Volt Gauge compatible with Electronic Pressure Sensors displays the engine or gearbox oil pressure.

ViewLine 52mm Gauges

The Veratron Marine ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with round bezel in identical colour. ViewLine accessories bezel concept offers true design flexibility in the layout of instrument panels.

The three attractive designs in black, white or chrome are suitable for every machinery instrument panel or special vehicle cockpit.

Specifications:

• 8 pole Tyco /Hirschmann MQS plug
• +/-3.6° angle degree accuracy over the entire display range
• Operating voltage 8-32 V
• Integrated warning alarm
• Input signal: standard s values
• Optional make-point switch can be connected
• Reverse polarity protection
• Anti-fog double lens
• Front side protection rating IP67
• 52 mm installation diameter
• 50 mm installation depth

Aftermarket package:

Gauge, Bezel, Rubber Seal, Spinlock, Connection cable, Installation Instructions, Safety Instructions
